Screening System Package (8 Cells)

Harga Call Us

Deskripsi Produk

Screening System Package (8 Cells)

The IKA Screening System is perfectly suited for constant current electrosynthesis in “multibatch” mode. The package with 8 undivided batch cells enables you to quickly carry out research on multiple electroconversions at the same time. In addition, you can combine the system with other equipment in the laboratory.

The usage of the single-cell screening system allows you to customize each reaction cell. The operator is able to individually pre-set an applied voltage of 0 – 32 V or 0 – 10 A current by using two voltage sources, each providing four outputs. Every reaction cell can be equipped with electrodes made of either different or the same electrode material. This depends strongly on the electro synthesis envisioned. All cells are arranged in a heating block that, if necessary, is heated up by a magnetic stirrer belonging to the scope of delivery. An external PT 1000 temperature sensor ensures the monitoring and control of the exact heating block temperature.

Up to 8 undivided cells can be operated simultaneously and individually
Synthesize sufficient quantities for GC, LC or NMR analysis processes
Separate control and pre-set for each cell
Easy testing of identical or differing electrolysis runs
Fast identification of ideal process parameters
Digital recording of test parameters
Simultaneous mixing and heating
Full temperature control (PT 1000) using heat block
Control and automation via Labworldsoft 6.0
Time and resources savings

Technical Data

Diameter	150 mm
Volume max.	0.160 l
Material in contact with medium	PTFE
Number of chambers for vials	8
Weight	24.9 kg
Permissible ambient temperature max.	200 °C
RS 232 interface	yes
Analog output	yes
Voltage	230 / 115 V
Frequency	50/60 Hz
